Anti-ligature Ventilation Grilles
Ventilation Grilles are often positioned on ceilings or high on walls. Their openings can be used to create a ligature point, making vent grilles a serious hazard in mental health environments. Plastic grilles can be broken to create sharp instruments, creating a risk to service users and staff. Contour’s Anti-ligature Ventilation Grilles reduce the ligature risk when installed over the top of standard Ventilation Grilles.
.png)
Technical Data
Manufacture
- Manufactured from 1.5mm Zintec or 1.5mm Magnelis steel if installing in wet areas.
- Chamfered design with front key-operated access.
- Anti-ligature IP3X rated grille (2mm holes at a 4mm staggered pitch) allows air to pass through.
- Standard grille sizes are designed to cover 4”, 6” 9” and 12 “ extractor fans.
Specification
Finish
- Powder coated finish RL9003 white as standard (other colours available)
- Exclusive BioCote® anti-microbial protection standard for RAL9003 white finishes.
Fixing
- Security fixing is used to provide access only to authorised staff.
Maintenance
- Robust, full frame provides easy access for cleaning and maintenance.
Sizing
Sizing
- Standard grille sizes are designed to cover 4”, 6” 9” and 12 “ extractor fans.
- 200mm x 200mm
- 250mm x 250mm
- 300mm x 300mm
- 350mm x 350mm
- 400mm x 400mm
- 450mm x 450mm
- 500mm x 500mm
- 550mm x 550mm
- 600mm x 600mm
- Bespoke sizes are also available upon request.
Colour Options Available
White
RAL 9003
Manufacture
Heat outputs to BS EN 442 Certification.
Outputs based on a mean radiator water temperature of 70°C and a room temperature of 20°C - Delta T 50°C
To acheive Delta T60 increase T50 figure by 20.5%
To calculate alternative Delta T requirements please refer to page
To convert BTU to Watts multiply by 0.293. To convert Watts to BTU divide by 0.293
